High efficient rapid continuous frequency cone yarn dentrifugal dehydrator

TY-RPE series package yarn extractor is suitable for extract water after cone yarn dyeing. Run credibly, easy operation, direct drive, low energy consumption, large output, uniform dehydration, innovative chrysanthemum-shaped inner cylinder can increase dehydration efficiency around 12%-15%, make cone yarn deformation smaller, its is the ideal equipment for dehydration process after dyeing bobbing yarn.

  • Model :

    TY-RPE

  • Payment :

    T/T;LC

  • Product Origin :

    China

  • Shipping Port :

    Shanghai Port,China
Inquiry now Download

cone yarn dehydrator



PRODUCT FEATURE

  • Package yarn dewatering machine: speed is 1530 RPM, moisture content of pure cotton after dehydration is about 40%, which improves the production efficiency and saves cost of next drying process.
  • Consistent moisture content after dehydration ensure the uniform moisture recovery rate of yarn after drying.
  • Cone yarn is supported by the chrysanthemum inner cylinder, which will not damage the yarn and dyeing bobbin when dewatering. The PLC automatic control system can work cycle after startup automatically.
  • Unique balance shock absorber design and balance protection device ensure run smoothly and safe operation.





STANDARD CONFIGURATION

  • Cast iron base and lift and drop support.
  • Stainless steel chrysanthemum-shaped inner cylinder, straight up drive motor.
  • Operation safety guarantee system, oil pressure lifting, falling rotary yarn frame.
  • Hydraulic lifting control system.
  • Programmable (PLC) automatic control system.



SPECIFICATION

 TY-RPE HIGH EFFICIENT CONTINUOUS CENTRIFUGAL CONE YARN DEHYDRATOR
Model TY-RPE-64 TY-RPE-96 TY-PE-128
Installed Power(KW) 9.5 12.5 12.5
Capacity(pcs) 320 pcs/H 480 pcs/H 640 pcs/H
