/ Home /Fabric Dyeing Machine /Automatic textile machinery high temperature pressure jet fabric cloth dyeing machine
high pressure jet fabric dyeing machine

Automatic textile machinery high temperature pressure jet fabric cloth dyeing machine

TY-JL631A automactic high pressure fabric dyeing machine is suitable for dyeing woven fabric, such as swim suit fabric, sportswear fabric, printed fabric and so on.

  • Model :

    TY-JL631A

  • Payment :

    LC;T/T

  • Product Origin :

    China

  • Shipping Port :

    Shanghai Port, China
Inquiry now

automatic woven fabric dyeing machine

  • fabric dyeing machine
    Dyeing
    Fabric dyeing machine is running at good condition in customer's dyeing plant.
  • #
    Export & Loading Container
    Professional team loading container, in case getting damage during transportation.
  • #
    Packing
    Sea freight standard package, plywood box, packing electrical cabinet, spare parts and so on.

PRODUCT FEATURE

  • TY-JL631A high pressure cloth fabric dyeing machine with lower liquor ratio 1:4-6, save water and energy after optimize the structure.
  • It is equipped water flow meter control liquor ratio, improving the reproducibility.
  • Auto system with convinient operation improve the uniform of dyeing, shorten temperature rising and cleaning time, increased production efficiency by 10-20%.



BASIC DATA

  • Max. working pressure: 0.4 Mpa
  • Max. working temperature: 140℃
  • Rate of temperature rising: 20-130℃, at the steam pressure above 8.0KG/cm2, around 25 mins
  • Rate of cooling: 130-80℃ need around 15mins, at cool water temperature is around 20℃, above P=1.2KG/cm2



SPECIFICATION

TY-JL631A AUTO HIGH PRESSURE OVERFLOW JET FABRIC DYEING MACHINE
MODEL TY-JL631A-250 TY-JL631A-500 TY-JL631A-1000
NO. OF TUBES 1 2 4
POWER 23.5KW 35KW 53.7KW
DIMENSION(LXWXHmm) 12000X1900X2650 12000X2600X2650 12000X4890X2650
