TY-JL630A high temperature fabric sample dyeing machine is suitable for dyeing knitted fabric and woven fabric with fast running speed, the design purpose is to dyeing small capacity and produce small bath of fabric.
Model :
ST-JL630A-30Payment :
T/T;LCProduct Origin :
ChinaShipping Port :
Shanghai Port, China
1st Generation Fabric Sample Dyeing Machine
TY-JL630A high temperature small capacity fabric dyeing machine can use the same dyeing technology with big capacity fabric dyeing machine, ensure the big capacity dyeing quality.
Low liquor ratio, less power consumption.
STANDARD STRUCTURE
SPECIFICATION
| MODEL | CAPACITY(KG) | POWER(KW) | DIMENSION(LXWXHmm) |
| TY-JL630A-5 | 4-6 | 5.9 | 1400 X 1170 X 1800 |
| TY-JL630A-15 | 8-15 | 7.7 | 2450 X 1200 X 2060 |
| TY-JL630A-30 | 20-30 | 9.3 | 3750 X 1260 X 2200 |
| TY-JL630A-60 | 40-60 | 11.2 | 4600 X 1400 X 2650 |
| TY-JL630A-120 | 80-120 | 11.2 | 6250 X 1700 X 2650 |
