Hank Yarn Dyeing Machine(NT)

You are in:

/ Home /Hank Yarn Dyeing Machine(NT) /Overflow full fill steam heating small capacity sample hank yarn dyeing machine
small capacity hank yarn dyeing machine

Overflow full fill steam heating small capacity sample hank yarn dyeing machine

Y series cabinet hank yarn sample dyeing machine is suitable for dyeing small quantity hank yarn before large production. Reducing energy consumption, wasting less yarn and saving production cost.

  • Model :

    Y10

  • Payment :

    T/T; LC

  • Product Origin :

    China

  • Shipping Port :

    Shanghai Port, China
Inquiry now
hank yarn sample dyeing machine

Y series overflow cabinet hank yarn dyeing machine is suitable for pre treatment and post treatment of cotton, wool, acrylic and blended yarn. It can do dyeing and finishing process: swelling, refining, bleaching, dyeing and softening.



Max. working temperature: 98℃

Heating rate: 20°C~98°C approx. 30minutes (dry saturated steam pressure at 6kg/cm2)

Cooling rate:98°C- 80°C approx. 15minutes (cooling water pressure at 3kg/cm2)

  • normal temperature hank yarn dyeing machine
    Dyeing
    Sample hank yarn dyeing machine is running at customer's factory.
  • steam heating hank yarn dyeing machine
    Different capacity
    Different capacity sample dyeing machine.
  • #
    Packing
    Sea freight standard packing, in case getting damage during transportation.

PRODUCT FEATURE

  • Sample hank yarn dyeing machine with the same system of big capacity cabinet overflow hank dyeing machine, with accurate positive and negative rotation controller, change the circulation direction automatically, ensure even dyeing.
  • Normal temperature hank yarn dyeing machine with special design of water pump, according the different dyeing technology, the running speed can be adjustable.
  • The space between hang yarn bar can be adjustable, it can dyeing different length of hank yarn, more flexible use.



STANDARD STRUCTURE

  • The main body and the part contact with dye liquor are made of high quality stainless steel.
  • Stainless steel main pump with high quality mechanical seal.
  • Stainless steel hang yarn bar (2 sets).
  • Stainless steel charging pump (the capacity of machine lower (include) Y20 without charging pump).
  • Dyestuff tank: mixing(the capacity of machine lower(include) Y200 isn't equipped mixing function), feeding, backflash, backflow and cleaning device



SPECIFICATION

Y CABINET HANK YARN DYEING MACHINE
Model  Power(KW) Capacity(KG)
Y5 1.1 2.2
Y10 1.1 4.5
Y20 1.1 9
Y30 2.25 14
Y50 2.25 23
Y100 2.95 45
Y200 4.75 90
Y300 5.5 140
Y400 7 185
Y600 9 275
Y800 12.5 360
Y1000 12.5 455
