DF241A high pressure package yarn dyeing machine is suitable for dyeing different material of yarn: sewing thread, embroidery thread, polyester, pure cotton, nylon, wool, hemp, flax, blended etc.
Model :
DF241APayment :
T/T; LCProduct Origin :
ChinaShipping Port :
Shanghai Port, China
PRODUCT FEATURE
DF241A series high temperature package yarn dyeing machine is suitable dyeing various material yarn, polyester, blended, cotton, flax, hemp, nylon, acylic, wool, etc.
The main motor is equipped with frequency inverter, allowing for limitless flow control to minimize energy consumption during startup and load-relieving operations.
Cone yarn dyeing machine with advanced controller.
STANDARD STRUCTURE
OPTIONAL CONFIGURATION
SPECIFICATION
| MODEL | SPINDLE X LAYER | NO. OF PACKAGES | MAIN POWER(KW) |
| DF241-21 | 1 X (3-5) | 3-5 | 2.2 |
| DF241- 40 | 3 X 4 | 12 | 3.7 |
| DF241- 43 | 4 X 4 | 16 | 5.5 |
| DF241- 43 | 4 X 5 | 20 | 5.5 |
| DF241- 53 | 6 X 5 | 30 | 7.5 |
| DF241- 75 | 12 X 6 | 72 | 11 |
| DF241- 85 | 18 X 6 | 108 | 15 |
| DF241- 85 | 18 X 7 | 126 | 15 |
| DF241- 90 | 19 X 8 | 152 | 18.5 |
| DF241- 110 |
28 X 8 | 224 | 22 |
| DF241- 120 |
36 X 7 | 252 | 22 |
| DF241- 120 |
36 X 8 | 288 | 30 |
| DF241- 130 |
39 X 9 | 351 | 37 |
| DF241- 140 | 46 X 9 | 414 | 37 |
| DF241- 160 |
62 X 9 | 558 | 55 |
| DF241- 170 |
69 X 10 | 690 | 55 |
| DF241- 186 |
90 X 10 | 900 | 75 |
| DF241- 200 |
108 X10 | 1080 | 90 |
| DF241- 200 |
108 X 11 | 1188 | 90 |
| DF241- 200 |
125 X 11 | 1375 | 110 |
